Fire Hose Reel

Features

• Side plates made of high quality mild steel, powder painted finish red
• Waterways made from none ferrous metals (aluminum alloy) which ensures corrosion free
• Maximum working pressure 15 bar, test pressure 20 bar
• Threaded inlet connection
• 180o double swivel
• Leakage free, rust free
• Stores less space
• Light weight
• Type-II ISI /CE marked hose pipe with bursting pressure of 36kg/cm2
• Shut off nozzle rotary operated, leak proof made up of high quality polymer



  Code No.

  Drum size

  Hose Diameter Length

  Distance Between
  Side Plates

  RFHR001

  525mm

  19mm x 30mtr

  155mm

  RFHR002

  525mm

  19mm x 30mtr

  200mm






Fire Hose Reel

Features

• Side plates made of high quality mild steel, powder painted finish red
• Waterways made from none ferrous metals which ensures corrosion free
• Maximum working pressure 15 Bar, test pressure 20 bar
• Double swivel
• Leakage free, rust free
• Light weight
• Type-I ISI marked hose pipe with bursting pressure of 22kg/cm2
• shut off nozzle rotary operated, leak proof made up of high quality polymer




  Code No.

  Drum size

  Hose Diameter Length

  Distance Between
  Side Plates

  RFHR003

  483mm

  19mm x 30mtr

  200mm
